Reinforced concrete expert

Reinforced concrete expert

Confidently design and safely check the critical member in your concrete structure.

IDEA StatiCa for Concrete

IDEA StatiCa helps you code-check all concrete details and cross-sections, in minutes.

RC cross-sections for beams, plates, walls, and columns
General or predefined geometry (40 templates)
All ULS/SLS checks. Fire resistance checks
Composite concrete-concrete sections

Beams of any topology. Non-linear deflections
Reinforcement and code-checking of walls and beam details
Crack and deflection checks. Compression softening. Tension stiffening
Automatic detection of optimal reinforcement positions

Design and code-check all your concrete details and cross-sections

Long-span beams

Cast-in-situ walls

Deep beams

Frame joints

Openings

Coupling beams

Solve the critical member

Once you’ve code-checked the critical members of a design, the rest of the job gets a lot easier. IDEA StatiCa Concrete lets you code-check the most complicated and critical parts of your project quickly and easily.

Complete design, analysis, and code-check, in minutes

Response N-M-M

Compressive concrete stress

Anchorage length

Stress in reinforcement

Cracks

Shear

A tool for all your SLS checks

Quickly generate complete serviceability limit state (SLS) checks of general walls – even for architecturally exposed members. The checks cover stress limitation, crack width, and deflection control.

Optimize reinforcement

IDEA StatiCa Concrete's powerful calculation core accounts for all discontinuity regions such as walls, dapped ends, openings, hangings, brackets, and areas above supports. IDEA StatiCa lets you analyze any concrete detail and determine how much reinforcement is needed and where.

All the ULS/SLS checks your projects require

Capacity N-M-M

Capacity N-M-M check is main concrete check of cross-section subjected to axial force and bending moments. Interaction diagram with its vertical and horizontal section is drawn for designed concrete cross-section. Diagram can be exported into image or DXF file. Data can be exported into Excel or into text file format.

Shear

Shear analysis with strut and tie models is adopted. The shape of links and stirrups can be selected to resist shear and/or torsion. Optimization of compression strut angle θ can be used. Longitudinal reinforcing bars can be set as bent-up bars to increase the shear resistance of members. Stress check at the interface between composite parts of the cross-section with consideration of interface type and reinforcement crossing the interface.

Stress limitation

Check of stresses in concrete fibers and reinforcement for short-term and long-term effects.

Crack width

Two approaches to take into account cracking. The first one, where crack width is calculated for reinforced, prestressed, and composite 1D and 2D concrete members. The concrete may be considered as effective or ineffective in tension. And the second one, where fictitious rotating cracks are considered, and concrete tensile strength is neglected except for its stiffening effect.

Deflection check

Deflection check of reinforced and prestressed concrete girders with the effect of cracking, concrete age (modulus of elasticity), creep, and shrinkage.

Detailing rules

Minimum and maximum reinforcement areas, spacing of longitudinal bars and shear reinforcement, limit value of tendon stress. etc. All detailing rules checks are referenced to code.

Solve unusual cross-section topology

Don't let your software limit your project. IDEA StatiCa Concrete helps you check reinforced concrete sections of any shape – typical, unusual, and even general cross-sections.

Complete reports. One tool

Working with multiple tools to generate all the checks for your reports takes up a lot of time. IDEA StatiCa Concrete generates and compiles ultimate and serviceability state checks (including interaction and fire resistance) into fully scalable and customizable reports.

Try idea statica for free

Download a free trial version of IDEA StatiCa

More about pricing Try 14 days for free
