How to design and code–check a pile cap

    Webinar date:

  • 2023-03-08T10:00:00.0000000Z
    (in your local time, 24-hour format)

Join the webinar and learn about

  • How to model pile caps
  • Which boundary conditions to use
  • How to apply the loads
  • Reinforcement design
  • Results interpretation - stress, cracks, and deflections


Lukas Juricek
Lukas Juricek Product Engineer
IDEA StatiCa
Petra Topinkova
Petra Topinkova Product Engineer
IDEA StatiCa
A pile cap usually forms the deep foundations of a structure, typically a multi-story building, bridge, or support base for heavy equipment. Are you interested in designing and code–checking all different pile caps easily? Join our free webinar.

The conventional Strut&Tie approach for discontinuity regions has a number of limitations, like lacking crack width checks.  On the contrary, the CSFM (Compatible Stress Field Method) implemented in the IDEA StatiCa Detail application gives a much more accurate analysis of D-regions and allows engineers to easily do all ULS and SLS checks required by the design code.

This webinar brings insight into the solution of pile caps with the anchoring of steel and concrete column. The webinar's goal is to show what elements are used for anchors and how to apply the load to concrete and anchors for the variant with a steel column. The application of the internal forces from FEA and boundary conditions for piles is introduced in the second variant with concrete columns. We end up the webinar with the presentation of the results, mainly stress, cracks, and deflections.

If you want to see more of IDEA StatiCa Detail in action, there are two other recorded webinars to watch:

Or browse our Support center for tutorials and read the theoretical background.

Webinar recording
