Frame joint

This article is also available in:

An example of a typical reinforced concrete frame joint reinforced with horizontal, vertical, and inclined rebars. Such a discontinuity region is a part of a frame usually designed in residential and industrial buildings. Modeled and analyzed in the IDEA StatiCa Detail application.

Sample files
