SCADA Pro

SCADA Pro

Steel

IDEA StatiCa works with your SCADA Pro. You can select any number of steel connections and members in SCADA Pro and export it to IDEA StatiCa for structural design and code-checking. All the beams, cross-sections, and internal forces are not just exported, but they are also synchronized if the SCADA Pro model changes. IDEA StatiCa and SCADA Pro give you an efficient workflow for your structural steel design that saves time, minimizes errors, and opens up optimization possibilities.

Workflow SCADA Pro and IDEA StatiCa

Workflow Steel Structural Engineer FEA

You do not need anything special to get started - just download and install both applications on the same PC, IDEA StatiCa will automatically detect the SCADA Pro installation and activate the plugin. And you can start exporting and designing steel connections right away!

Export, design, synchronize, generate a report

Ready to solve various steel connections? SCADA Pro combined with IDEA StatiCa will allow you to model, design, load, and check steel connections of any topology and loading. And make this data available to your colleagues or subcontractors doing detailing and fabrication

Scope of the BIM link

Linked applications: IDEA StatiCa Connection

Link activated directly inside SCADA Pro application, more information at: https://www.scadapro.com/el/scada-pro-prostheta/idea-statica-connection/

SCADA Pro BIM link intro

Video available on: https://www.youtube.com/watch?v=wKzoj7TVHGo

Note

SCADA Pro BIM link is developed and maintained by a third-party integration company. IDEA Statica does not take any responsibility for this integration. All technical requirements and questions must be addressed to the developer.
