Steel Detailer
Stop remodeling connections and insist on IFCs
STOP REMODELING
Instead of recreating models from PDFs, import connection files from your connection designer directly into your CAD software, ensuring accurate models that align with the structural engineer’s design, minimizing the risk of costly errors or over-design.
- Import the structure from the CAD model into Checkbot
- Transfer the critical connections from Checkbot to Viewer
- Export IFC or 3D DWG files, with annotated sketches, for your CAD tool
SHARE YOUR OUTCOMES
Use your CAD models for communicating with connection designers and structural engineers.
- Import your CAD model into Checkbot, including all connection details
- Using Checkbot, export and share the models with your structural engineer for checking in Viewer
- Export using IFC, the standard for fabricators, directly from Checkbot
O QUE AS FERRAMENTAS GRATUITAS LHE OFERECEM
IDEA StatiCa Checkbot e Viewer fornecem as ferramentas necessárias para uma troca de dados eficaz, gratuitamente, com uma conta IDEA StatiCa Basic User. Evite atrasar a sua equipa com conflitos de licenças e mantenha todos a par do trabalho.
- Obtenha todas as ferramentas de gestão de dados gratuitamente
- Inclui Checkbot, Viewer, Connection Library e Campus
- Tenha sempre acesso à versão mais recente e às integrações
